8x19 Class

ROTATION RESISTANT
8x19S (1/2" - 3/4") | 8x26WS (1/2" - 3/4")

The size relationship between strands and cores gives these ropes
increased bendability over six strand ropes of the same diameter.
  • Crush and rotation resistant rope.
  • lncreased bendability.
  • Used as a hoist rope in elevator applications.
Download PDF
Available as Standard
Diameter (in) Diameter (mm) Weight (Ib/ft) Minimum Breaking Force (tons for 2000 Ibs) EIPS 1960 Minimum Breaking Force (tons for 2000 Ibs) EEIPS 2160
1/2 12.7 0.47 10.1 11.6
9/16 14.3 0.60 12.8 14.7
5/8 15.9 0.73 15.7 18.1
3/4 19.1 1.06 22.5 25.9
7/8 22.2 1.44 30.5 35.0
1 25.4 1.88 39.6 45.5
1 1/8 28.6 2.39 49.8 57.3
1 1/4 31.8 2.94 61.3 70.5

Standard Lubricants

LUBE - A I Our lightest standard lube for enhanced handling.
LUBE - B I Excellent lubricity and corrosion protection.
LUBE - C I Heavy lube designed to give extra lubrication, corrosion protection,
enhanced durability, and reduced wear and heat generation.
LUBE - D I Heavy C lube that is also applied at stranding process. Creates
heaviest standard coat available for elevated heat and winter conditions.
SPECIAL LUBES I Specialty lubes available upon request.
**EEIPS made to order.
Contact your local representative
for availability.
